AEON-TX HEVC Transmitter

A compact and feature-rich COFDM digital video transmitter, specifically designed for high quality wireless link applications. With proven Domo COFDM and next generation HEVC encoder technology at its core enabling Ultra High Definition images the small size and actively cooled enclosure give maximum operational performance. Designed to offer future proof connectivity, the unit supports native 12G-SDI,
dual 6G-SDI, quad 3G-SDI, as well as SFP+ expansion. Two true balanced audio inputs are included with phantom power. The transmitter has an integrated control panel with sunlightreadable LCD display covering all major functions and has 16 user-defined presets, as well as IP based control.

The HEVC codec used in AEON products offers a step change in compression efficiency over H.264 systems, whilst maintaining low end to end latency suitable for live events.

  • Ultra-low latency HEVC SD, HD and 4K encoding
  • Video formats up to 2160p60, 10-bit and 4:2:2 chroma sampling, future HDR support
  • Industry standard DVB-T modulation for interoperability with existing systems
  • Domo Broadcast UMVL modulation for enhanced high frequency/high speed performance
  • Controlled via IP or integrated sunlight-readable LCD display
  • Designed for sports & events coverage, newsgathering and wireless studio camera applications
  • #Integrated return channels for bi-direction IP connectivity and low bandwidth telemetry
  • #Scalable return channel for talk-back to camera control to return video
  • Low power consumption and active cooling for extended field performance

#Future development
