CDD-564A, CDD-564AL & CDD-562AL IP Demodulators

The CDD-564A, CDD-564AL and CDD-562AL are our next generation integrated IP demodulators providing industry leading performance in a 1 RU package at a competitive price. They are designed to receive up to four independent 70/140 MHz or L-Band channels (depending on model) and combine the receive data into a single 10/100Base-T Ethernet port for transmission onto the LAN. The demodulators are designed to operate with Comtech EF Data’s CDM-570/L-IP and CDM-570A/L-IP IP-enabled modems.

  • Independent demodulators
    • CDD-564A: Four 70/140 MHz demodulators
    • CDD-564AL: Four L-band demodulators
    • CDD-562AL: Two L-band demodulators
    • CDD-564A: 50 to 90 or 100 to 180 MHz
    • CDD-562AL & CDD-564AL: 950 to 2250 MHz
    • 16 kbps to 10.239 Mbps data rate
    • BPSK, QPSK, 8PSK/8-QAM, 16-QAM demodulation
    • VersaFEC® low latency LDPC forward error correction (Constant Coding & Modulation Mode)
    • 2nd Generation Turbo Product Coding (TPC) forward error correction
    • 5%, 10%, 15%, 20%, 25% and 35% Filter Rolloff
  • Static IP routing for unicast and multicast
  • Management via SNMP, Web or Telnet
  • IGMP v1 and v2
  • 10/100Base-T- Ethernet data interface (RJ-45)
  • 10/100Base-T- Ethernet management interface (RJ-45)
  • Firmware upgrade via FTP
  • Front panel LEDs for unit status, stored event indication and the status of each receive channel
  • LNB support: 10 MHz reference and LNB power
  • Compatible with the CDM-570/L-IP (TPC) and CDM-570A/L-IP (TPC or VersaFEC)

Typical Users

  • Enterprise
  • Broadcasters
  • Internet Service Providers
  • Oil Field Service Providers
  • Maritime
  • Government & Military

Common Applications

  • Disaster Recovery & Emergency Communications
  • Enterprise
  • Offshore & Maritime Communications
  • Satellite News Gathering
